Título: Certification of the absorbed energy of Charpy V-notch reference test pieces for tests at 20 °C. ERM®-FA013ci : certification report
Resumen:El presente informe de certificación describe el procesamiento y la caracterización de ERM® -FA013ci, un lote de probetas de referencia certificadas Charpy V-notch de acero aleado para la energía media absorbida (KV). Los juegos de cinco de estas probetas se utilizan para la verificación indirecta de las máquinas de ensayo de impacto pendular según la norma ISO 148-2 [1]. La KV se define operacionalmente y se refiere a la energía de impacto necesaria para romper una probeta con muescas en V de dimensiones normalizadas, tal como se define en la norma ISO 148-1 [2]. El valor certificado de ERM-FA013ci se hace trazable al Sistema Internacional de Unidades (SI), a través del valor certificado trazable al SI del lote maestro ERM® - FA013ba [3], ensayando probetas de ERM-FA013ci y ERM-FA013ba en condiciones de repetibilidad sobre un péndulo Charpy de referencia verificado y calibrado con herramientas calibradas trazables al SI. El valor certificado sólo es válido para percutores con un radio de punta de 2 mm. El valor certificado es válido a (20 ± 2) °C. El valor certificado para KV y la incertidumbre expandida asociada (k = 2 correspondiente a un nivel de confianza de aproximadamente el 95 %) se calcularon de conformidad con la norma ISO 17034:2016 [4] y la Guía ISO 35:2017 [5] para la media de un conjunto de cinco piezas de ensayo. La incertidumbre incluye contribuciones relacionadas con la posible falta de homogeneidad y la caracterización. Antes de la publicación del material de referencia certificado, el proyecto de certificación se sometió a una revisión por pares.
Summary:This certification report describes the processing and characterisation of ERM® -FA013ci, a batch of Charpy V-notch alloy steel certified reference test pieces certified for the average absorbed energy (KV). Sets of five of these test pieces are used for the indirect verification of pendulum impact test machines according to ISO 148-2 [1]. KV is operationally defined and refers to the impact energy required to break a V-notched test piece of standardised dimensions, as defined in ISO 148-1 [2]. The certified value of ERM-FA013ci is made traceable to the International System of Units (SI), via the SI-traceable certified value of the master batch ERM® - FA013ba [3], by testing test pieces of ERM-FA013ci and ERM-FA013ba under repeatability conditions on a Charpy reference pendulum verified and calibrated with SI-traceably calibrated tools. The certified value is valid only for strikers with a 2 mm tip radius. The certified value is valid at (20 ± 2) °C. The certified value for KV and the associated expanded uncertainty (k = 2 corresponding to a confidence level of about 95 %) were calculated in accordance with ISO 17034:2016 [4] and ISO Guide 35:2017 [5] for the mean of a set of five test pieces. The uncertainty includes contributions related to possible inhomogeneity and characterisation. Before release of the certified reference material, the certification project was subjected to peer-review.
Fecha publicación: 17-01-2023
Autor: Centro Común de Investigación; Linsinger, Thomas ; Vanderveken, Francine
ISBN / ISSN: 978-92-76-61567-5 / 1831-9424
Link: https://bit.ly/3GQIbxI
Palabras clave: certificación comunitaria , ensayo , informe de investigación , método de evaluación , producto metálico , resistencia de los materiales
Keywords: Community certification , evaluation method , metal product , research report , resistance of materials , testing
